BAYD86 Series Explosion-proof Emergency Exit Light Fittings

Brand Name : WAROM

Model Number : BAYD86

Can be used in : Zone 1 and Zone 2 Zone 21 and Zone 22 Class I, Zone 1 and Zone 2 Class I, Division 1, Groups A, B, C, D

Designed with test button : Press the button, lamp shall automatically enter into emergency status.

Ultra-bright LED lamp : low power consumption and long service life up to 50,000 hours; energy saving and environmental protection.

Contact Now

Product Introduction

BAYD86 Series Explosion-proof Emergency Exit Light Fittings


Specification
Global (IECEx) IECEx (applied for)
Gas and dust

Ex mb eb ib IIC T6 Gb

Ex tb IIIC T80℃ Db

Europe (ATEX) ATEX (applied for )
Gas and dust

II 2 G Ex mb eb ib IIC T6 Gb


II 2 D Ex tb IIIC T80℃ Db

Certificates IECEx; ATEX;
Conformity to standards EN; IEC
Degree of protection IP66


Data
Enclosure

GRP (glass fiber reinforced polyester)
Exposed fastener Stainless steel
Rated voltage 100~277V AC 50/60Hz, 100~250V DC, 12~48V AC/DC
Lamp LED lamp (working voltage DC 3.6V)
Power consumption 8W
Emergency time 180min
Rated capacity 800mAh
Charging time 16h
Earthing protection M5 (internal & external earth bolts)
Ambient temperature -60℃~+60℃
Terminal 3 x 1.5~2.5mm² (L+N+PE)
Cable entries

2 x M25 x 1.5 plugs
Cable gland DQM-I is recommended.
Weight 8kg
Download

BAYD86 Series Explosion-proof Emergency Exit Light Fittings

(Download here:BAYD86 Series Explosion-proof Emergency Exit Light FittingsBAYD85 Series Explosion-proof Emergency Exit Light Fittings.pdf)
