HRMD95 Series-Proof Distribytion Panels With Specialized Hinge Structure

Name: HRMD95 SeriesProof Distribytion Panels With Specialized Hinge Structure
Brand: WAROM
Price: 1 USD

Brand Name : WAROM

Model Number : HRMD95

Place of Origin : CHINA

Flamepmof enclosure (Ex d llB+H2) : which can be used as feeddistribution equipment in control and distribution system(suchas distribution box, switch box of main circuit ,control box, terminalbox or motor starting box etc.)

Copper-free Aluminium Alloy enclosure : powder coated surface

Equipped with specialized hinge structure : which can preventthe flameproof joints from damage when opening and closingthe box, and greatly prolong the service life of box.

Contact Now

Product Introduction

HRMD95 Series-Proof Distribytion Panels With Specialized Hinge Structure

Specification

Global (IECEx)	IECEx PCET 24.0030X
Gas and Dust	Ex db llB+H2 T口'Gb Ex db fia Ga]lB+H2 Tㄩ"Gb Ex db [ib Gb] lB+H T口"Gb Ex tb llC T’Db
Europe (ATEX)	applied for
Gas and Dust	ll 2 G Ex db llB+H2 T口'Gb ll 2 G Ex db [ia Ga] llB+H2 T口"Gb ll2 G Ex db [ib Gb] llB+H2 T口"Gb II 2 D Ex tb llIC T口"Db 'See table for max. dissipated power
Certificates	IECEx; ATEX;
Conformity to standards	EN 60079-0, EN 60079-1, EN 60079-11, EN 60079-31 IEC 60079-0, IEC 60079-1, IEC 60079-11, IEC 60079-31
Degree of protection	IP66
Ambient temperature	-60℃(-40℃)≤Ta≤+40(+60℃)

Data

Material	Copper-free Aluminium Alloy, powder coated surface,Window grey (RAL7040)
Dimensions	As per design
Rated voltage	MAX. 1000V AC 50/60Hz; MAX. 1500V DC
Rated current	Max.2000A
Internal&external earthing	M8/M8
Cable entries	Standard MX1.5 plug

Download

HRMD95 Series Series-Proof Distribution Panels

(Download here:HRMD95 Series Explosion-proof Distribution Panels.pdf .)

Global (IECEx):IECEx PCET 22.0011X
(Download here:

IECEx PCET 24.0030X.pdf )
